8-Channel DIN35 Rail Digital Input/Output Modules

Product Description:

Features:

The device boasts a range of features that make it a versatile choice for encoder counter and speed measurement applications. It can support up to 8 encoders to count simultaneously while being able to identify forward and reverse movements. The device also offers 16 independent DI high-speed counters. The encoder count value is saved automatically, even after a power outage. The DI input / power supply isolation is rated at 3000VDC, ensuring top-notch safety.

The device can be conveniently programmed to suit the user's requirements. Its RS-485/232 interface is instrumental in clearing and setting the count value. The power supply range is between 8 and 32VDC, ensuring compatibility with diverse power sources. The device's DIN35 rail installation is optimized for centralized wiring and is user-friendly. The module address and baud rate can be programmed according to the user's needs. The device's dimensions of 120 mm x 70 mm x 43mm make it compact and portable.

Technical Parameters:

The communication interface was intentionally designed to have high anti-interference capabilities, ensuring that it runs smoothly and efficiently even in electrically noisy environments. The interface is equipped with protective features, such as ±15KV ESD protection, to safeguard against electrical discharges that can cause damage and malfunctions.

In the event of unexpected electrical surges, the communication interface can withstand a certain amount of electromagnetic interference and continue to function correctly. This is in part due to the transient suppression diodes that have been integrated into the module. These diodes are effective in suppressing various surge pulses, which helps protect the module and reduces the risk of damage.

The design also incorporates an internal digital filter that can suppress power frequency interference from the power grid, thus ensuring that the data transmission remains stable and accurate. The communication response time has also been optimized to be less than 100mS, allowing for quick and efficient data transfer.

The checksum feature offers further protection against any potential errors or malfunctions that may occur during data transmission. The checksum can be set as required, providing an additional layer of customization and ensuring that data is transferred accurately without any data corruption.

Applications:

The module address, baud rate, and other programming functionalities are available for the user's convenience. Through this feature, users can easily customize and modify specific settings on their modules to better fit their needs.

With the use of this programming capability, users have the option to change their module address, which is essential for connecting multiple modules on the same network. Additionally, users can adjust the baud rate to ensure uninterrupted data transfer between the module and connected devices.

Overall, the programming functionality provided in this module enables greater efficiency and flexibility for the user, allowing them to optimize their device for their specific use case.

Customization:

WAYJUN offers product customization services for the WJ69-485 Digital I/O Modules. These modules are designed and manufactured in shenzhen and come in a sleek green color. With a weight of 100g, they are lightweight and easy to install.

Our product customization services allow you to tailor the WJ69-485 to meet your specific needs. We can customize the response time of the DI counter to 1ms, ensuring that you receive real-time data. Additionally, we can configure the module to support Modbus RTU communication protocol, providing a reliable and efficient means of transmitting data.

The WJ69-485 Digital I/O Module has 8 channels, making it ideal for applications that require multiple inputs and outputs. We can customize the module to support 8-channel encoder inputs, allowing you to accurately track and monitor industrial processes.

Furthermore, we can customize the output voltage range of the module to meet your specific requirements. With an output voltage range of 8-32VDC, the WJ69-485 is suitable for a wide range of applications.

Packing and Shipping:

Product Packaging:

The Digital I/O Modules will be packaged securely in a sturdy cardboard box with ample padding to prevent any damage during transportation. Each module will be individually wrapped in anti-static packaging to avoid any damage from static electricity. The box will also include a user manual and necessary cables for installation.

Shipping:

We offer free shipping for the Digital I/O Modules to anywhere within the United States. International shipping is available for an additional fee. All orders will be processed within 24 hours and shipped via a reputable courier service with tracking information provided. Delivery times may vary depending on location, but typically take 3-5 business days within the United States and up to 10 business days for international orders.
